Electric Wire Rope
Hoist Solutions
Effortless Lifting,
Maximum Efficiency
At Atul Crane & Components, we have established ourselves as a premier manufacturer of electric wire rope hoists in India. Our state-of-the-art in-house facility allows us to produce heavy-duty systems with capacities reaching 25 tons, using cutting-edge techniques and premium materials.
We focus on delivering exceptionally durable, safe, and flexible designs that are easy to maintain, significantly reducing operational downtime. Every hoist is tailored to meet specific industrial challenges, ensuring high performance across both heavy-duty and precision-focused applications, all backed by our dedicated after-sales support.
What Is An Electric
Wire Rope Hoist?
An electric wire rope hoist is a robust material handling system designed to lift and move heavy loads in a wide range of industrial and commercial settings. It comprises key components like a motor, gearbox, rope drum, wire rope, and lifting hook. The motor powers the gearbox, which in turn rotates the rope drum to wind the wire rope, raising or lowering the load with precision and control.
These hoists are operated either through a push-button pendant or via a wireless remote, allowing for safe and convenient handling from a distance. Built for accuracy and efficiency, wire rope electric hoists are ideal for demanding environments like warehouses, manufacturing plants, and construction sites.
As a trusted electric wire rope hoist manufacturer in India, we provide electric wire rope hoists in multiple lifting capacities and heights, with designs that comply with stringent safety standards to ensure reliable performance under heavy-duty conditions.
Technical Overview- Electric Wire Rope Hoist
| Capacity | Our electric wire rope hoists deliver heavy-duty performance with lifting capacities from 1 to over 25 tons, as per your needs. |
| Motor Power | Our electric wire rope hoists feature motor power ranging from 1.5 kW to 5.5 kW, ensuring efficient performance. |
| Power Supply | 380V/415V, 50Hz, 3-phase |
| Lifting Speed | Standard lifting speed of 3 m/min, with adjustable speed options available for enhanced control and flexibility. |
| Wire Rope Material | Crafted from high-quality steel or stainless steel, our wire ropes ensure strength, durability, and safe lifting performance. |
| Wire Rope Diameter | 8 mm to 12 mm |
| Frame Construction | Welded steel frame |
| Hook Type | Our rope hoists come equipped with forged steel hooks with safety latch, ensuring secure and reliable load handling. |
| Control System | The electric wire rope hoists come with a pendant control system with an optional wireless remote for seamless and flexible operation. |
| Safety Features | Our rope hoists are equipped with numerous safety features like overload protection, emergency stop functions, limit switches and electromagnetic brakes. |
| Gearbox Type | The electric wire rope hoists feature precision-engineered planetary gearboxes for smooth and efficient performance. |
| Protection Rating | IP54 or IP65 |
| Compliance | The rope hoists are designed and manufactured in full compliance with international safety standards. |
| Customization | We provide custom-made hoist trolleys tailored to your beam size, ensuring optimal balance, enhanced safety, and reduced wear and tear. |
| Specified Capacity | Tested to withstand 125% above the specified capacity |
Technical Features
Of Electric Wire Rope Hoist
Revolutionary compact design facilitating efficient load handling
Highly-customized hoist models according to the requirement
World-class hoists with true lift capability that minimizes hook movement horizontally -hook moves horizontally only 10mm during a one-meter lift
Modern hook forging design for safer load rigging
DC Disk motor brake
IP55 rated for outdoor use
Premium rope for wear resistance
Heavy-duty fan-cooled motors
Benefits Of Electric Wire Rope Hoist
An electric wire rope hoist offers the following benefits:
Why Choose Us?
Equipped with a state-of-the-art hoist and crane manufacturing facility, we deliver high-quality material handling equipment built with advanced machinery. Our skilled engineers serve a wide range of industries, ensuring precision handling and on-time delivery every step of the way.
Trusted Expertise
Readily Available Spares
Advanced Technology
Safety And Compliance
Affordable Solutions
24/7 Customer Support
Frequently Asked Questions
Our electric wire rope hoist can handle loads 1 tons to 20 tons.
Our electric wire rope hoists are powered by high-performance industrial electricity (typically 380V-440V, 3-phase, 50Hz/60Hz) to ensure consistent heavy-duty performance.
A wire rope hoist uses a drum driven by an electric motor to wrap or unwrap a wire rope, which is connected to a hook block to lift or lower loads vertically.
The wire rope diameter is carefully selected based on the lifting capacity, typically ranging from 8mm to 24mm high-tensile steel rope for maximum safety.
